Blue/grey Superflexible Hose
SKU: SFSD
Technical Characteristics
Application
Suitable for heavy duty suction and delivery of liquids such as water, oil, acid, etc in the agriculture and civil engineering industry.
Tube
With flexible PVC inner hose and rigid PVC spiral. The spiral rigid core is fused into the hose through simultaneous extrusion, providing high pressure and abrasion resistance. Due to the lower friction coefficient, operators can easily drag the hose.
Reinforcement
Shock resistant PVC spiral
Cover
Blue / Grey. Corrugated Outer
Temperature Range
-5°C to +65°C
Safety Factor
3:1
Sizes
| Inch | Inner Diameter (ID) (mm)  | Outer Diameter (OD) (mm)  | Working Pressure (BAR)  | Working Pressure (PSI) | Bend Radius (BR) (mm)  | Coil Length (Metres)  |
|---|---|---|---|---|---|---|
| 1 1/4" | 32 | 41 | 6 | 90 | 130 | 30 |
| 1 1/2" | 38 | 47 | 6 | 90 | 150 | 30 |
| 2" | 51 | 61 | 5 | 75 | 200 | 30 |
| 2 1/2" | 63 | 75 | 5 | 75 | 250 | 30 |
| 3" | 76 | 90 | 4 | 60 | 300 | 30 |
| 4" | 102 | 116 | 4 | 60 | 410 | 30 |
Conversions shown are approximate and rounded.
