Medium Duty Blue Layflat
SKU: LFB
Technical Characteristics
Application
Mainly used for the delivery of water in agriculture, construction, civil engineering, mining and landscaping
Tube
Blue
Reinforcement
High strength Polyester filament reinforcement
Cover
Blue PVC
Temperature Range
-10°C to +60°C
Safety Factor
3:1
Sizes
| Inch | Inner Diameter (ID) (mm)  | Outer Diameter (OD) (mm)  | Working Pressure (BAR)  | Working Pressure (PSI) | Bend Radius (BR) (mm)  | Coil Length (Metres)  |
|---|---|---|---|---|---|---|
| 1" | 25 | 4 | 60 | 10, 25, 100 | ||
| 1 1/4" | 32 | 4 | 60 | 10, 25, 50, 100 | ||
| 1 1/2" | 38 | 4 | 60 | 10, 25, 50, 100 | ||
| 2" | 52 | 4 | 60 | 10, 25, 50, 100 | ||
| 2 1/2" | 63 | 4 | 60 | 100 | ||
| 3" | 76 | 4 | 60 | 10, 25, 50, 100 | ||
| 4" | 102 | 4 | 60 | 100 | ||
| 6" | 153 | 3 | 45 | 100 | ||
| 8" | 203 | 3 | 45 | 100 |
Conversions shown are approximate and rounded.
